qt10 15 block machin20
qt10 15 fully automatic concrete block brick making machine hydraulic interlocking cement brick production line
qt10 15 fully automatic concrete block brick making machine hydraulic interlocking cement brick production line
qt10 15 fully automatic concrete block brick making machine hydraulic interlocking cement brick production line
qt10 15 fully automatic concrete block brick making machine hydraulic interlocking cement brick production line
qt10 15 fully automatic concrete block brick making machine hydraulic interlocking cement brick production line
qt10 15 fully automatic concrete block brick making machine hydraulic interlocking cement brick production line

QT10-15 Fully Automatic Concrete Block Brick Making Machine Hydraulic Interlocking Cement Brick Production Line

Original price was: $39,000.00.Current price is: $37,000.00.

The QT10-15 is a fully automatic, high-strength, and high-efficiency block molding machine. Its name, “QT10-15,” means it can produce 10 standard hollow bricks (400mm × 200mm × 200mm) every 15 seconds.

Key Features:

Fully Automatic Operation: From material feeding, placement, vibration pressing, demolding, to finished product conveying, pallet transfer, and stacking, everything is automatically controlled by a programmable logic controller (PLC). Human intervention is mainly for monitoring, maintenance, and raw material preparation.

High-Efficiency Production: It can easily produce over 19,200 hollow bricks per day (8 hours).

Multi-Purpose Functionality: By changing different molds, the QT10-15 can produce a wide variety of cement products, including:
Various blocks: hollow blocks, solid blocks. Paving bricks: grass pavers, permeable bricks, plaza bricks, curb stones, etc. Ideal for medium and large-sized building material factories and brick factories. Projects for the resource utilization of solid waste such as construction waste, fly ash, and slag. Production of precast components for various municipal engineering projects.

Category:
QT10-15 brick machine factory production description
a. Raw material use wheel loader delivery into batching machine , need 1 worker
b. Cement delivery into mixer, from cement silo by cement screw conveyor
c. Mixer mixing material, then delivery to brick machine, conveyor here need 1 worker
d. After making blocks, delivery blocks to a stacker
e. Forklift deliver blocks to curing area , need 1 worker
f. Curing area : Curing need 10-15 days, then take blocks out from pallet; need 1-2 workers
g. After curing, take blocks out from pallet, pallet delivery to Pallet feeding machine by forklift
Blocks laying in block stock area
Automatic Building Material Machinery Concrete Block Brick Making Machine Hydraulic Interlocking Cement Brick Production Line factory
Automatic Building Material Machinery Concrete Block Brick Making Machine Hydraulic Interlocking Cement Brick Production Line factory
Automatic Building Material Machinery Concrete Block Brick Making Machine Hydraulic Interlocking Cement Brick Production Line details
Automatic Building Material Machinery Concrete Block Brick Making Machine Hydraulic Interlocking Cement Brick Production Line details
Automatic Building Material Machinery Concrete Block Brick Making Machine Hydraulic Interlocking Cement Brick Production Line manufacture
Automatic Building Material Machinery Concrete Block Brick Making Machine Hydraulic Interlocking Cement Brick Production Line factory
ALL THE KEY PARTS ARE HEAT TREATED
MORE HARDER AND DURABLE!

SPECIFICATIONS FOR QT10-15 AUTOMATIC BLOCK MACHINE
A
QT10-15 Host brick machine
a. Automatic pallet system
b. Automatic material feeding system
(2)QT10-15 Automatic brick plant technical information:
B
Block receiver
QT10-15 Host machine total power
47.7 KW
C
Stacker, it could layer 4-5 pallets blocks
Molding cycle
15 s
D
8m conveyor
Host brick machine size
5300*2050*2700
E
JS750 Mixer bigger power, 38.6 KW
Berat badan
8000 KGS
F
Batching machine PLD 800, power, 9 KW
Pallet size
1300*870 mm
SIMENS Programmable Logic Controller
